USED ββ/ Rim / 609X36C / 40GTS / Single Wall / No eyelets / Others / Black / Disc
Size = 609X36C
Item number: G90529
€ 0,00
In stock : 0
Business customer? Request an account or log in and order on account with our competitive trading prices!
| Beoogd gebruik | Cargo , Vintage |
|---|---|
| BSD maat | 609 |
| FIETS Inch maat | 28 X 2 |
| Aantal spaken/spaakgaten | 40 |
| Geschikt voor velgrem | Nee |
| Kleur | Zwart |
| Interne breedte van de velg | 36C |
| Type velg | Others |
| Materiaal van de velg | Staal |
| Enkelwandig / Dubbelwandig | Enkelwandig |
| Gebuste velg | Ongebust |
| Nieuw of gebruikt | Gebruikt |
Note BSD 609mm!
Very rare 40 hole steel rim. This was used in transport bikes and military bikes until the middle of the last century.
Rim specifications:
Brand: Others
Type: Others
Colour: Black
Size (Inch/MM): 609X36C
External width (MM): 54
Internal width (MM): 36
Average weight (GR): 1875
Material: Steel
Single-walled / Double-walled: Single-walled
Single eyelets / Double eyelets: No eyelets
Number of spoke holes: 40GTS
Spoke nipple size: 11G
Braking surface present: No
Data for using the Sapim spoke length calculation tool:
Internal rim diameter (MM *Not ERD*): 597
Rim thickness (MM): 1
Number of spokes in the wheel: 40
Number of sprocket side crossings: Optional
Number of left side crossings: Optional
Link to spoke length calculation: https://www.sapim.be/spoke-calculator
